Assembly Technical Drawing

  Bottle Caddy Assembly Technical Drawing

 Bottle Caddy is created by four parts which used in Assembly environment. I prefer to use FreeCAD program. You can use any CAD program which has Assembly workbench.

 Assembled bottle caddy contains eight parts. Four parts are copied, so I will share four technical drawings.

 Click technical drawings to magnify them.

 If you want to watch the video how to create assembly of these drawings. You check below video.

All parts are included with details and dimensions. Drawings are tested and used in Assembly workbench.

 If you want see more assembly technical drawings. You can check my blog.I usually share technical drawing with different levels for CAD program users.

 You can subscribe my youtube channel to understand drawing of technical drawings. If you have an interest with different CAD programs, I recommend to watch my videos.
